SCION xA (EM00D0U)
141
: Parts Location
Code See Page Code See Page Code See Page
B2 28
F10
A 28 O1 29
C10 A 30
F10
B 28
S1
A 29
C11 B 30 F15 32
S1
B 29
E5 30 I10 31
:
Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
2 22 Engine Room R/B (Engine Compartment Left)
:
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1A 24 Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1F
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1G
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1H
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1K
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1O
1T 24 Floor Wire and Instrument Panel J/B (Lower Finish Panel)
:
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IB1 36 Floor Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
ID2
36
Engine Room Main Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
ID3
36
Engine Room Main Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
IF2 37 Engine Wire and Instrument Panel Wire (Left Side of the Blower Unit)
:
Ground Points
Code See Page Ground Points Location
ED 34 Front Fender Apron LH
IF 36 Instrument Panel Brace LH
