SCION xA (EM00D0U)
61
: Parts Location
Code See Page Code See Page Code See Page
C10 30 H1 28 J4 A 31
C12 30 H2 28 J5 B 31
:
Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
2 22 Engine Room R/B (Engine Compartment Left)
:
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1A
24
Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1B
24
Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1F
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1M
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1O
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
:
Ground Points
Code See Page Ground Points Location
IE 36 Left Kick Panel
