SCION xA (EM00D0U)
63
: Parts Location
Code See Page Code See Page Code See Page
C12 30 F18 30 J5 B 31
F16 28 F19 30
F17 28 J4 A 31
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1J
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
EC1 34 Engine Room Main Wire and Lamp Wire (Behind the Radiator Side Support LH)
ID3 36 Engine Room Main Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
Ground Points
Code See Page Ground Points Location
EB 34 Front Fender Apron RH
IE 36 Left Kick Panel
