66
SCION xA (EM00D0U)
Turn Signal and Hazard Warning Light
: Parts Location
Code See Page Code See Page Code See Page
C6 30 F7 28 R7 33
C10 30 F8 28 R8 33
C12 30 J1 31 R14 33
F5 28 J2 31 R15 33
F6 28 J8 31
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1B 24 Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1F
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Floor Wire and Instrument Panel J/B (Lower Finish Panel)
Floor Wire and Instrument Panel J/B (Lower Finish Panel)
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IA1 36 Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IH1 37 Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
Ground Points
Code See Page Ground Points Location
EA 34 Front Fender Apron RH
ED 34 Front Fender Apron LH
IE 36 Left Kick Panel
IF 36 Instrument Panel Brace LH
IG 36 Right Kick Panel
BH 38 Left Quarter Pillar
To Next Page
