SCION xA (EM00D0U)
69
: Parts Location
Code See Page Code See Page Code See Page
B5 32 D4 32 J7 31
C4 30 D5 32 J9 32
C10 A 30 D6 32 L3 32
C11 B 30 D7 32 P7 B 33
D2 30 I11 31 S14 A 33
Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
2 22 Engine Room R/B (Engine Compartment Left)
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1A 24 Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1G
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1S 24 Floor Wire and Instrument Panel J/B (Lower Finish Panel)
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IB1 36 Floor Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
IE1 37 Roof Wire and Floor Wire (Upper Side of the Cowl Side Panel LH)
BE2 38 Back Door No.1 Wire and Floor Wire (Quarter Panel LH)
Ground Points
Code See Page Ground Points Location
IE 36 Left Kick Panel
IF 36 Instrument Panel Brace LH
BJ 38 Back Door Panel LH
To Next Page
