SCION xA (EM00D0U)
73
: Parts Location
Code See Page Code See Page Code See Page
C7 30 F4 28 R3 B 31
C10 A 30 F19 30 R6 31
C11 B 30 J7 31 R7 33
C12 30 J9 32 R8 33
E6 30 L1 32 R16 C 31
F1 28 L2 32 S16 31
F2 28 O2 31
F3 28 R2 A 31
:
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1B 24 Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1F
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1H
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1J
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1M
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1N
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1O
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1P
1Q
1R
1S 24 Floor Wire and Instrument Panel J/B (Lower Finish Panel)
:
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
BE2
38
Back Door No.1 Wire and Floor Wire (Quarter Panel LH)
BE3
38
Back Door No.1 Wire and Floor Wire (Quarter Panel LH)
:
Ground Points
Code See Page Ground Points Location
EA 34 Front Fender Apron RH
ED 34 Front Fender Apron LH
IE 36 Left Kick Panel
IF 36 Instrument Panel Brace LH
BH 38 Left Quarter Pillar
BI 38 Right Quarter Pillar
BJ 38 Back Door Panel LH
