SCION xA (EM00D0U)
75
: Parts Location
Code See Page Code See Page Code See Page
H7 32 R7 33 S6 31
J9 32 R8 33
:
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1B 24 Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1T 24 Floor Wire and Instrument Panel J/B (Lower Finish Panel)
:
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
BE3 38 Back Door No.1 Wire and Floor Wire (Quarter Panel LH)
:
Ground Points
Code See Page Ground Points Location
BH 38 Left Quarter Pillar
BJ 38 Back Door Panel LH
