SCION xA (EM00D0U)
157
I
: Parts Location
Code See Page Code See Page Code See Page
J1 31 J8 31
:
Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
2 22 Engine Room R/B (Engine Compartment Left)
:
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1D
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1E
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1K
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1M
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1N
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1O
1P
1R
:
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
EB1 34 Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B)
IA1
36
Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IA2
36
Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IB1 36 Floor Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
IE1 37 Roof Wire and Floor Wire (Upper Side of the Cowl Side Panel LH)
IF2 37 Engine Wire and Instrument Panel Wire (Left Side of the Blower Unit)
IG1 37 Instrument Panel Wire and A/C Sub Wire (Right Kick Panel)
IH1 37 Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
BE3 38 Back Door No.1 Wire and Floor Wire (Quarter Panel LH)
BG1 38 Back Door No.1 Wire and Rear Door No.1 Wire (Right Side of the Back Door Panel)
:
Ground Points
Code See Page Ground Points Location
EA
34
Front Fender Apron RH
EB
34
Front Fender Apron RH
EC 34 Cylinder Head
ED 34 Front Fender Apron LH
IE 36 Left Kick Panel
IF 36 Instrument Panel Brace LH
IG 36 Right Kick Panel
BH 38 Left Quarter Pillar
BI 38 Right Quarter Pillar
BJ 38 Back Door Panel LH
