Position of Parts in Body
P11
R14
T4
R9
R1
2
S1
0
R8
R1
0
P1
4
P1
0
R1
3
S8
P1
6
R1
1
P7
(*2)
* 1:w/ Sliding Roof
* 2:w/o Sliding Roof
S14
(*1)
S13 T5 R15 P12 P8
S9S11P13P9P15S7 S12 R7
P 7 Personal Light
P 8 Power Window Control SW Front RH
P 9 Power Window Control SW Rear LH
P10 Power Window Control SW Rear RH
P 11 Power Window Motor Front LH
P12 Power Window Motor Front RH
P13 Power Window Motor Rear LH
P14 Power Window Motor Rear RH
P15 Pretensioner LH
P16 Pretensioner RH
R 7 Rear Combination Light LH
R 8 Rear Combination Light RH
R 9 Rear Speaker LH
R10 Rear Speaker RH
R11 Rear Window Defogger
R12 Rear Window Defogger
R13 Rear Wiper Motor
R14 Remote Control Mirror LH
R15 Remote Control Mirror RH
S 7 Side Airbag Sensor Front LH
S 8 Side Airbag Sensor Front RH
S 9 Side Airbag Sensor Rear LH
S10 Side Airbag Sensor Rear RH
S 11 Side Airbag Squib LH
S12 Side Airbag Squib RH
S13 Sliding Roof Control ECU and Motor
S14 Personal Light
Sliding Roof Control SW
T 4 Tweeter LH
T 5 Tweeter RH
