SCION xA (EM00D0U)
81
When the ignition SW is turned on, current flows to TERMINAL 2 of the washer motor, TERMINAL 1 of the rear wiper motor
through the WIPER fuse.
1. Rear Wiper Normal Operation
With the ignition SW turned on and rear wiper and washer SW turned to ON position, current flows to TERMINAL 1 of the
rear wiper motor to TERMINAL 2 of the rear wiper and washer SW to TERMINAL 5 to GROUND. Causing the rear wiper
motor operated.
2. Washer Operation
With the ignition SW turned on and the rear wiper and washer SW turned to ON position, when the wiper SW is turned
further (ON+ washer position), current flows to TERMINAL 2 of the washer motor to TERMINAL 3 to TERMINAL 3 of the
rear wiper and washer SW to TERMINAL 5 to GROUND so that the washer motor rotates and the window washer emits a
water, only while the switch is fully turned.
When the wiper SW is off and then turned to washer position (Wiper off side), only the washer operates.
: Parts Location
Code See Page Code See Page Code See Page
C14 30 R13 33 W1 29
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1A 24 Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1N
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IB2 36 Floor Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
ID3 36 Engine Room Main Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
BE2 38 Back Door No.1 Wire and Floor Wire (Quarter Panel LH)
