SCION xA (EM00D0U)
89
The current always flows to TERMINAL 14 of the door lock control relay through the D/L fuse.
1. Manual Lock Operation
When the door lock control SW or door key lock and unlock SW are operated to LOCK position, a lock signal is input to
TERMINAL 7 or 9 of the door lock control relay and causes the door lock control relay to function. The current flows from
TERMINAL 14 of the door lock control relay to TERMINAL 1 to the door lock motors to TERMINALS 2 and 13 of the door
lock control relay to TERMINAL 25 to GROUND and the door lock motors locks the door.
2. Manual Unlock Operation
When the door lock control SW or door key lock and unlock SW are operated to UNLOCK position, an unlock signal is input
to TERMINAL 8, 10 or 11 of the door lock control relay and causes the door lock control relay to function. The current flows
from TERMINAL 14 of the door lock control relay to TERMINALS 2 and 13 to the door lock motors to TERMINAL 1 of the
door lock control relay to TERMINAL 25 to GROUND and the door lock motors unlocks the door.
3. Double Operation Unlock Operation
When the door key lock and unlock SW front LH is turned to the unlock side, only the driver’s door is unlocked. By turning
the door key lock and unlock SW front LH to the unlock side, a signal is input to TERMINAL 10 of the door lock control relay,
and if the signal is input again within 3 seconds by turning the SW to the unlock side again, current flows from TERMINAL 13
of the door lock control relay to the door lock motors to TERMINAL 1 of the door lock control relay to TERMINAL 25 to
GROUND, causing all the other doors are unlocked.
: Parts Location
Code See Page Code See Page Code See Page
B5 32 D10 32 J2 31
D3 30 D11 32 J4 A 31
D4 32 D12 32 J5 B 31
D8 32 D13 32 J8 31
D9 32 J1 31
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1L 25 Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1S 24 Floor Wire and Instrument Panel J/B (Lower Finish Panel)
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IA1
36
Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IA2
36
Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IB2 36 Floor Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
IH1
37
Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
IH2
37
Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
BA1 38 Rear Door LH Wire and Floor Wire (Center Pillar LH)
BB1 38 Rear Door RH Wire and Floor Wire (Center Pillar RH)
BE3 38 Back Door No.1 Wire and Floor Wire (Quarter Panel LH)
Ground Points
Code See Page Ground Points Location
IE 36 Left Kick Panel
IG 36 Right Kick Panel
