102
SCION xA (EM00D0U)
ABS, TRAC and VSC
Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
2 22 Engine Room R/B (Engine Compartment Left)
3 23 ABS R/B (Engine Compartment Right)
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1A
Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
EB1 34 Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B)
IC1 36 Engine Room Main Wire and Floor Wire (Left Side of the Cowl Panel)
ID2
Engine Room Main Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
Engine Room Main Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
IF2 37 Engine Wire and Instrument Panel Wire (Left Side of the Blower Unit)
BC1 38 Skid Control Sensor Rear LH Wire and Floor Wire (Front Side of the Quarter Wheel House Inner Panel LH)
BD1 38 Skid Control Sensor Rear RH Wire and Floor Wire (Front Side of the Quarter Wheel House Inner Panel RH)
Ground Points
Code See Page Ground Points Location
ED 34 Front Fender Apron LH
IE 36 Left Kick Panel
IF 36 Instrument Panel Brace LH
