SCION xA (EM00D0U)
105
Multiplex communication system (CAN) uses a serial communication protocol and communicates with a differential voltage.
In this network system, TERMINALS CANH and CANL are used for communication between the ECUs and sensors, and
excellent data communication speed and communication error detecting facility are provided.
This system is working for the following systems:
∗ ABS
∗ Air Conditioning
∗ Engine Control
∗ TRAC
∗ VSC
: Parts Location
Code See Page Code See Page Code See Page
A17 30 J1 31 S1 A 29
D1 30 J7 31 S15 31
E5 30 J10 31 Y1 31
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1H
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
ID2 36 Engine Room Main Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
Ground Points
Code See Page Ground Points Location
IE 36 Left Kick Panel
