2.5 Mechanical Specification
• Unit size (mm): 77mm(L)×53mm(W)×20.5mm(H)
• Display area (mm) : 63.9mm(L)×27.4mm(W)
• No. of Keys: 4
• Door: Main battery door
• Environmental concern: Drop test
– GEO Spec., QFD-07
Thermal test
– GEO Spec., QFD-09
Vibration test – GEO Spec., QFD-10
Compression Test – Sharp Spec.
2.6 Appearance
B
C
D
E
F
G
HI
A
A : Battery door F : Read/Confirm key
B : Door lock G : Right key
C : Chain H : Left key
D : Buzzer I : Select key
E : Screen
