SCORPION J075 - Page 21

Ref. Description Ref. Description
1 Phillips screw 5/32-32NCx5/8” 42 Gib
2 Retainer 43 Fence Bracket
3 Spring Knob 44 Flat Washer 10X20X3.0T
4 Spring 45 Flat Washer 10.5X28X3.0T
5 Retaining Washer 46 Cap Screw 3/8”-16NCX1-1/2”
6 Rivet 2x5 47 Guide Bar 3/8” X 3/8” X 225
7 Chip Breaker 48 Spring Pin 4x20
10 Handwheel 49 Bolt 3/8”-24NFX89MM
11 Set Screw 1/4-20NCx3/8” 50 Lock Washer 10.2X18.5
12 Bushing 51 Bearing Housing
13 Set Screw 5/16”-18NCX3/8” 52 Bearing 6202-2NSE
14 Flat Washer 10x22x0.8T 53 Knife
15 Adjusting Nut 54 Cutter Head
16 Spring Pin 3x25 55 Countersunk Screw M5x0.8Px12
17 Lead Screw 56 Knife Lock Bar
18 Knob 57 Knife Lock Screw
19 Knob 58 Key 5x5x25
20 Pointer 59 Bearing 6203-2NSE
21 Hex Nut 1/2”-12NC(19.05BX11.11H) 60 Bearing Housing
22 Lock Washer 13x22.7 61 Cutter Head Pulley
23 Pivot Pin 62 Push Block
24 Front Ball Crank 63 Fence Body
25 Rear Ball Crank 64 Countersunk Screw 5/16”-18NCX1-5/8”
26 Shoulder Pin 65 Fence Handle Assembly
27 Base 65-1 Handle Shaft
29 In-feed Table 65-2 Handle Knob
30 Set Screw 66 Fence Linkage
31 Hex Nut 1/4”-20NC(11BX5.5H) 67 Hex Nut 1/2”-20NF (19.05BX6.35H)
32 Lock Screw 7/8” X 1/4” -20NC X 1” 68 Block
33 Cutter Guard 69 Block
34 Lock Lever 70 Bolt
35 Fixed Plate 71 Lock Nut
36 Cap Screw 5/16”-18NCX3/4” 72 Spring Pin 4x12
37 Pin 73 Hex Head Bolt
38 Spring 74 Stop Plate
39 Spring Seat 75 Flat Washer 13X28X3.0T
40 Ball Handle 76 Fence Locking Handle
41 Out-feed Table 77 Stop Plate
Parts List (J075)
