Ref. Description Ref. Description
78 Hex Nut 7/16”-14NC (17.4BX9.52H) 107 Motor Cord SJT 16AWG/3Cx 358mm
79 Hex Nut 5/16”-18NC (12.7BX6.75H) 108 Lower Pulley Guard Cover
80 Hex Head Bolt 5/16”-18NCX1-3/4” 109 Lower Pulley Guard Backing Plate
81 Linkage 110 Motor Pulley
82 Swivel Block 111 Carriage Bolt 5/16”-18NCX5/8”
83 Hex Nut 5/8”-18NF (23.81BX8H) 112 Motor Mounting Bracket
84 Spacer 113 Carriage Bolt 5/16”-18NCX20MM
85 Hex Nut 3/8”-16NC (14.2BX8.33H) 114 Dust Hood Cover
86 Screw 115 Dust Hood Outlet
87 Link Plate 116 Wing Screw M5X0.8PX12
88 Fence Slide Block 117 Flange Bolt 3/8”-16NCX3/4”
89 Hex Head Bolt 5/16”-18NCX1” 118 Switch Assembly
90 Plate 118-1 Switch Pad
91 Flat Washer 6.6X13X1.0T 118-2 Switch Front Cover
92 Phillips Screw 1/4”-20NCX1/2” 118-3 Switch Body
94 Upper Pulley Guard 118-4 Switch Back Cover
95 Flat Washer 6.7X16X1.0T 118-5 Phillips Screw M4X0.7PX25
96 Phillips Screw 1/4”-20NCX3/8” 119 Knife Setting Gauge
97 Flat Washer 4.3X10X1.0T 120 E Ring ETW-9
98 Phillips Screw 5/32”-32NCX1/4” 121 Knife Gauge Bar
99 Stand Assembly 124 Key 5x5x30
99-1 Stand Front Top Shelf 125 Allen Key 3mm
99-2 Stand Front Cross Brace 126 Open Wrench 8-10mm
99-3 Stand Rear Cross Base 127 Open Wrench 12-14mm
99-4 Side Top Shelf (left and right) 128 Knife Setting Gauge Assembly
99-5 Side Cross Brace (left and right) 129 Spring
99-6 Stand Rear Top Shelf 130 Strain Relief
99-7 Stand Leg 131 Nut 3/16” X24NC
100 Power Cord 132 Sprocket Washer BW-5
101 V-Belt A32 133 Switch Plate
102 Switch Cord SJT 16AWG/3Cx 515mm 134 Stud/Spacer
103 Rubber Foot 135 Sponge Gasket
104 Flat Washer 8.5X16X1.8T 136 Push Block Storage Bracket
105 Motor 1HP/110/220V/60HZ/1PH/2P/14A/7A 137 Allen Key 4mm
106 Lock Washer 8.2x15.4
22
