Air ow
The machine takes in room temperature air at the
lower right front and forces warm air out the lower
left front. Restricting the airow will adversely affect
the ability of the ice machine to make ice.
Scotsman Ice Systems are designed and
manufactured with the highest regard for safety
and performance. They meet or exceed the
standards of agencies like U.L.
Scotsman assumes no liability or responsibility of
any kind for products manufactured by Scotsman
that have been altered in any way, including the
use of any parts and/or other components not
specically approved by Scotsman.
Scotsman reserves the right to make design
changes and/or improvements at any time.
Specications and designs are subject to change
without notice.
Warm Air Out
Air Intake
Ice Making
Area
Control Panel
To Next Page
