Scotsman MF 88 - Wiring Diagrams; MF;MFN 88 AS Electrical Schematic (400;50;3+N)

Page 17
Page 17
SECTION VI
WIRING DIAGRAMS
This section is provided as an aid in understanding
the electrical circuit of the MF/MFN 88.
The Wiring Diagrams in this Sections is:
Wiring diagram - MF/MFN 88 AS (400/50/3+N).
WARNING - When conducting a conti-nuity
check of the MF/MFN 88:
1. Disconnect the main power source.
2. DO NOT use an incandescent lamp or
jumper wire, conduct all tests with a
voltohm-meter.
