GENIUS
BIKE OWNERS MANUAL
RECOMMENDED AIR PRESSURE
kg/bar All Low Position
700 900
45 4.1 3.1
50 4.6 3.6
55 5.1 4.2
60 5.6 4.7
65 6.2 5.3
70 6.7 5.9
75 7.3 6.5
80 7. 9 7.0
85 8.5 7.6
90 9.1 8.2
95 9.8 8.8
100 10.4 9.5
105 11.1 10.1
110 11.8 10.7
lbs/psi All Low Position
700 900
99 59 44
110 66 52
121 74 60
132 82 69
143 90 77
154 98 85
165 106 94
176 115 102
187 123 111
198 132 119
209 142 128
220 151 137
231 161 146
242 172 155
Genius Pressure Charts - For Manual, Naked Rider Weight
20 scott-sports.com 21
GENIUSENGLISH
BIKE OWNERS MANUAL
SET-UP GENIUS WITH NUDE 2 OR DT M3 SHOCK
The Set-Up of the Scott Nude 2 or DT M3 Shock can be easy done within a few
minutes.
1. remove the valve cap of the valve (S5) located on the shock housing (S3).
2. mount the shock pump with its adaptor on the valve
3. pls take into account that it takes some air pressure from inside the shock
to drive the indicator on the pump. Make sure to balance at least this air loss
when you make a check of the air pressure of the shock. Pls also note that
the indicators of shock pumps have a tolerance of max. 10%
4. pump the recommended pressure into the shock. On the shock you will
find a decal showing the recommended air pressure of the positive chamber
according to the rider’s weight.
5. when you reached the needed pressure remove the pump and put the valve
cap on the valve
Important:
For all adjustments of the air spring the remote lever has to be in position “all travel”
To adjust the air pressure of the air chamber of the Scott Nude 2 or DT M3 Shock
please refer to the following instruction:
