1. loosen the cable fixing screw (S7) by turning it counter clockwise with a 2mm allen
key.
2. insert a new cable via lever hole and cable housing and push it into the shock as
shown around the remote wheel (S6).
3. tighten the cable and fix the cablefixing screw (S7) by turning it clockwise with a
2mm allen key and a max. tightening torque of 1.6Nm.
4. cut the cable approx. 20mm away from the remote wheel.
Fix it by squeezing it with pliers.
