SCOTT SCALE 970 User Manual

111 |
ENGLISH
ROAD BIKE | OWNER’S MANUAL 2021
Component What to do Before Monthly Annually Other
every ride
Headset Check for bearing play ·
Regrease o
Metal surfaces Polish (except: rim sides · every
of rim brakes, rotors) 6 months
at least
Hubs Check for bearing play ·
Regrease o
Pedals (all) Check for bearing play ·
Pedals (clipless) Clean and grease locking mechanism ·
Seat post/stem Check bolts ·
Disassemble and regrease o
Carbon: new assembly paste (no grease!)
Front/rear derailleur Clean and grease ·
Quick-releases Check seat ·
Nuts Check and retighten, if necessary ·
(mudguards etc.)
Valves Check seat ·
Cables Disassemble and regrease o
gears/brakes
If you have a certain degree of mechanical skills, experience and suitable tools,
such as a torque wrench, you should be able to do the checks marked · by your-
self. If you come across any defects, take appropriate measures without delay. If
you are in doubt or if you have any questions, contact your SCOTT dealer.
Jobs marked o are best left to your SCOTT dealer.
WARNING
For your own safety, bring your SCOTT bike to your SCOTT dealer for its first
inspection after 100 to 300 kilometres, 5 to 15 hours of initial use or four to
six weeks, and at the very latest after three months.

SCOTT SCALE 970 Specifications

General

Crankset	Shimano FC-MT511-1, 32T
Saddle	Syncros Belcarra Regular 2.5
Chain	KMC X12
Spokes	Stainless Black 15G / 1.8mm
Frame	Alloy 6061 Custom Butted Tubing
Fork	RockShox Judy Silver TK, 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 12 Speed
Shifters	Shimano Deore SL-M6100-R / Rapidfire Plus
Brakes	Shimano BR-MT200, hydraulic disc
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros
Tires	Schwalbe Rapid Rob 29x2.25"
Handlebar	Syncros Alloy 6061, T shape Flat, 9° back sweep, 740mm
Seatpost	Syncros / 31.6x400mm
Rotor	Shimano SM-RT30 CL, 180mm(F) / 160mm(R)
H'stem	Syncros Alloy 6061
Headset	Syncros OE Press Fit, Tapered 1.5" - 1 1/8"
Hub (Front)	Shimano MT400
Hub (Rear)	Shimano MT400
Rims	Syncros / 32H
