SCOTT SCALE 970 User Manual

ENGLISH
95 |
ROAD BIKE | OWNER’S MANUAL 2021
e fd
WARNING
Bear in mind that by overtightening the bolts the stem can crush the steer-
er tube. In particular forks with carbon steerer tubes are highly sensitive
to overtightening the steerer tube clamping at the stem. Risk of breakage!
Make sure the clamping area is absolutely free of grease when any of the
clamping faces is made of carbon. If necessary, use carbon assembly paste
in the clamping areas to ensure maximum clamping.
Check the secure seat of the stem by taking the front wheel between your
legs and trying to turn the handlebars and stem relative to the wheel (e). A
loose stem can cause an accident.
Never change the preloading mechanism in the inside of the fork steerer
tube. Never install a star nut in carbon fork steerer tubes.
N OTICE
Do not overtighten the upper bolt, it only serves to adjust the headset play.
SAFETY INSTRUCTIONS
If you do not succeed in adjusting the headset, this can have several reasons.
If you are not absolutely sure, ask your SCOTT dealer for help.
LIGHTING OF YOUR SCOTT BIKE
For riding on public roads a functioning lighting set (f) is obligatory (see the
chapter “Legal requirements for riding on public roads”).

SCOTT SCALE 970 Specifications

General

Crankset	Shimano FC-MT511-1, 32T
Saddle	Syncros Belcarra Regular 2.5
Chain	KMC X12
Spokes	Stainless Black 15G / 1.8mm
Frame	Alloy 6061 Custom Butted Tubing
Fork	RockShox Judy Silver TK, 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 12 Speed
Shifters	Shimano Deore SL-M6100-R / Rapidfire Plus
Brakes	Shimano BR-MT200, hydraulic disc
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros
Tires	Schwalbe Rapid Rob 29x2.25"
Handlebar	Syncros Alloy 6061, T shape Flat, 9° back sweep, 740mm
Seatpost	Syncros / 31.6x400mm
Rotor	Shimano SM-RT30 CL, 180mm(F) / 160mm(R)
H'stem	Syncros Alloy 6061
Headset	Syncros OE Press Fit, Tapered 1.5" - 1 1/8"
Hub (Front)	Shimano MT400
Hub (Rear)	Shimano MT400
Rims	Syncros / 32H
