ENGLISH
| 114
OWNER’S MANUAL 2021 | ROAD BIKE
RECOMMENDED TORQUE SETTINGS FOR DISC BRAKES ON YOUR
SCOTT BIKE
Component Shimano
1
SRAM/Avid
2
Tektro
3
TRP
4
Magura HS
5
(Nm) (Nm) (Nm) (Nm) (Nm)
Brake calliper mount 6 - 8 9.5 6 - 8 6 - 8 6
on frame/fork
Brake lever unit on handlebars
- Single-bolt clamp 4 - 8 3 - 5.5 5 - 7 3 - 5 4
- Two-bolt clamp 3
Union screws of cable at grip 5 - 7 5 4
and normal cable at brake calliper
Brake cable connector at 5 - 7 5 5 - 6 3
brake calliper (disc tube cable)
Expansion tank cap 0.3 - 0.5
Bleeding device brake calliper 4 - 6 4 - 6 4
Bleeding device brake lever 0.5 - 1 0.5
Brake disc fixing (6-holes) 4 6.2 4 - 6 4 - 6 4
Brake disc fixing (centerlock) 40 - 50 40
Hose (union nut) direct connection 5 - 7 4
Slave cylinder (bleeder screw) 4
Brake pad retainer at brake calliper 2 - 4 1 3 - 5 2.5
Cable clamp at brake calliper 6 - 8 6 - 8 6 - 8
1
www.shimano.com
2
www.sram.com
3
www.tektro.com
4
www.trpbrakes.com
5
www.magura.com
These values are reference values of the above-mentioned component manu-
facturers. Be sure to observe the values in the manuals of the component manu-
facturers. These values do not apply to the components of other manufacturers.
WARNING
Some components have the maximum permissible torque values printed on
them. Use a torque wrench and never exceed the maximum torque value! If
you are in doubt or if you have any questions, contact your SCOTT dealer.
N OTICE
Due to the unmanageable number of components on the market, SCOTT is not
in a position to foresee every product that will be replaced or newly assembled
by third parties. Therefore SCOTT denies any liability for such kind of additions
or modifications with regard to compatibility, torque values etc. Whoever
assembles or modifies the SCOTT bike shall ensure that the bike was assembled
according to the state of the art in science and technology.
