SCOTT SCALE 970 User Manual

ENGLISH
93 |
ROAD BIKE | OWNER’S MANUAL 2021
e fd
THE HEADSET ON THE SCOTT BIKE
The headset (e) connects the fork to the frame, but allows it to move freely.
It must turn with virtually no resistance, if the SCOTT bike is to run straight,
stabilising itself as it travels. Shocks caused by uneven road surfaces expose the
headset to considerable levels of stress. In this way it can become loose and go
out of correct adjustment.
WARNING
Riding the bicycle with a loose headset increases the stress on fork and
bearings. This can lead to damage to the fork. Risk of falling!
Checking and readjusting
Check the headset for play by placing your fingers around the upper head
tube race. Bring your weight to bear on the saddle, pull the front brakes with
your other hand and push the SCOTT bike firmly back and forth with the wheel
remaining on the ground (f). If the bearing has play, you will feel the upper head
tube race moving in jerks relative to the lower head tube race - visible as a small
gap in between the head tube races.

SCOTT SCALE 970 Specifications

General

Crankset	Shimano FC-MT511-1, 32T
Saddle	Syncros Belcarra Regular 2.5
Chain	KMC X12
Spokes	Stainless Black 15G / 1.8mm
Frame	Alloy 6061 Custom Butted Tubing
Fork	RockShox Judy Silver TK, 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 12 Speed
Shifters	Shimano Deore SL-M6100-R / Rapidfire Plus
Brakes	Shimano BR-MT200, hydraulic disc
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros
Tires	Schwalbe Rapid Rob 29x2.25"
Handlebar	Syncros Alloy 6061, T shape Flat, 9° back sweep, 740mm
Seatpost	Syncros / 31.6x400mm
Rotor	Shimano SM-RT30 CL, 180mm(F) / 160mm(R)
H'stem	Syncros Alloy 6061
Headset	Syncros OE Press Fit, Tapered 1.5" - 1 1/8"
Hub (Front)	Shimano MT400
Hub (Rear)	Shimano MT400
Rims	Syncros / 32H
