SCOTT SCALE 970 User Manual

ENGLISH
117 |
ROAD BIKE | OWNER’S MANUAL 2021
e fd
NOTES ON WEARING PARTS
Some components of your SCOTT bike are subject to wear due to their function
(a+b). The rate of wear will depend on care and maintenance and the way you
use your SCOTT bike (mileage, riding in the rain, dirt, salt etc.). SCOTT bikes
that are often left standing in the open may also be subject to increased wear
through weathering.
The components below require regular care (c+d) and maintenance. The follow-
ing parts which have reached their limit of wear must be replaced:
Drive chain
Brake pads
Brake fluid (DOT)
Brake discs/rotors (e)
Brake cables
Brake cable housings
Rim sides (of rim brakes) (f)
Rubber grips
Chainrings
Chainstay protection
Bearings in hubs, joints etc.
Handlebar tape
Tyres
Sprockets
Saddle covering / saddle
Pulleys
Bowden cables
Cable housings
Inner tubes
Lubricants

SCOTT SCALE 970 Specifications

General

Crankset	Shimano FC-MT511-1, 32T
Saddle	Syncros Belcarra Regular 2.5
Chain	KMC X12
Spokes	Stainless Black 15G / 1.8mm
Frame	Alloy 6061 Custom Butted Tubing
Fork	RockShox Judy Silver TK, 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 12 Speed
Shifters	Shimano Deore SL-M6100-R / Rapidfire Plus
Brakes	Shimano BR-MT200, hydraulic disc
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros
Tires	Schwalbe Rapid Rob 29x2.25"
Handlebar	Syncros Alloy 6061, T shape Flat, 9° back sweep, 740mm
Seatpost	Syncros / 31.6x400mm
Rotor	Shimano SM-RT30 CL, 180mm(F) / 160mm(R)
H'stem	Syncros Alloy 6061
Headset	Syncros OE Press Fit, Tapered 1.5" - 1 1/8"
Hub (Front)	Shimano MT400
Hub (Rear)	Shimano MT400
Rims	Syncros / 32H
