SCOTT SCALE 970 User Manual

ENGLISH
69 |
ROAD BIKE | OWNER’S MANUAL 2021
e fd
You can check the battery’s state of charge at any time. To do so, press one of
the control buttons and keep it in this position for half a second at least. The
LED on the control unit indicates the state of charge:
– green light is on for about 2 seconds: state of charge of the battery 100 % (f)
– green light blinks 5 times: state of the charge of the battery approx. 50 %
– red light is on for about 2 seconds: state of the charge of the battery approx.
25 %
– red light blinks 5 times: state of charge of the battery empty
The capacity of the battery and hence the distance that you can ride drop grad-
ually over time. This is unavoidable. You must replace the battery if the distance
that you can ride is no longer sufficient for your requirements.
WARNING
Only use the supplied charger to charge the battery!
N OTICE
If the rechargeable battery is not used for a longer period of time, it should
neither be empty nor full. Keep the nearly charged battery (50 % to 60 %)
in a dry, cool place and out of the reach of children. After three months at
the latest you should check the state of charge. Protect the contact areas
of your rechargeable battery with the protective covers before storing the
battery.
Charging of a (fully discharged) battery takes around one and a half hours.

SCOTT SCALE 970 Specifications

General

Crankset	Shimano FC-MT511-1, 32T
Saddle	Syncros Belcarra Regular 2.5
Chain	KMC X12
Spokes	Stainless Black 15G / 1.8mm
Frame	Alloy 6061 Custom Butted Tubing
Fork	RockShox Judy Silver TK, 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 12 Speed
Shifters	Shimano Deore SL-M6100-R / Rapidfire Plus
Brakes	Shimano BR-MT200, hydraulic disc
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros
Tires	Schwalbe Rapid Rob 29x2.25"
Handlebar	Syncros Alloy 6061, T shape Flat, 9° back sweep, 740mm
Seatpost	Syncros / 31.6x400mm
Rotor	Shimano SM-RT30 CL, 180mm(F) / 160mm(R)
H'stem	Syncros Alloy 6061
Headset	Syncros OE Press Fit, Tapered 1.5" - 1 1/8"
Hub (Front)	Shimano MT400
Hub (Rear)	Shimano MT400
Rims	Syncros / 32H
