SCOTT SCALE 970 User Manual

ENGLISH
73 |
ROAD BIKE | OWNER’S MANUAL 2021
psi bar psi bar
80 5.5 115 7.9
85 5.9 120 8.3
90 6.2 125 8.6
95 6.6 130 9.0
100 6.9 135 9.3
105 7.2 140 9.7
110 7.6 145 10.0
e fd
Clincher and folding tyres and rim alone are not able to hold the air. Therefore,
an inner tube has to be placed inside the tyre (f) to retain the air pressure.
Rims of clincher and folding tyres require in general a high-value rim tape over
the complete width of the rim base. This rim tape protects the inner tube from
the braking heat which could make the tyre burst.
In the case of tubular tyres that must be glued on the rim the tube is already
integrated into the tyre and can be neither removed, nor patched in the case of
a puncture. This type of tyre requires special rims without rim flanges.
If necessary, read the respective manuals before working on such kind of tyres.
Tubeless tyres can only be used in combination with specifically de-
signed wheels. Pay attention to the manufacturer’s type designations (e.g.
“2way-fit”/“tubeless ready“).
With reduced pressure tubeless tyres can be used as clincher tyres. The ap-
propriate pressure for 75-kg / 165-lbs-cyclists is usually 7 bar and for 65-kg /
143-lbs-cyclists 6 bar. Make sure the pressure is not below 4.5 bar. Observe the
marking on the tyre sides regarding the maximum pressure.
WARNING
Replace tyres with a worn tread or with brittle or frayed sides. Dampness
and dirt penetrating the tyre can cause damage to its inner structure. The
tube might burst. Risk of falling!
If you mount a new tyre with another size than the standard tyre mounted,
it might be possible that the clearance between the front of your shoe and
the wheel will be reduced when you ride at reduced speed. Also observe the
space between fork and frame. Risk of accident!

SCOTT SCALE 970 Specifications

General

Crankset	Shimano FC-MT511-1, 32T
Saddle	Syncros Belcarra Regular 2.5
Chain	KMC X12
Spokes	Stainless Black 15G / 1.8mm
Frame	Alloy 6061 Custom Butted Tubing
Fork	RockShox Judy Silver TK, 100mm travel
Rear Derailleur	Shimano Deore RD-M6100 12 Speed
Shifters	Shimano Deore SL-M6100-R / Rapidfire Plus
Brakes	Shimano BR-MT200, hydraulic disc
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros
Tires	Schwalbe Rapid Rob 29x2.25"
Handlebar	Syncros Alloy 6061, T shape Flat, 9° back sweep, 740mm
Seatpost	Syncros / 31.6x400mm
Rotor	Shimano SM-RT30 CL, 180mm(F) / 160mm(R)
H'stem	Syncros Alloy 6061
Headset	Syncros OE Press Fit, Tapered 1.5" - 1 1/8"
Hub (Front)	Shimano MT400
Hub (Rear)	Shimano MT400
Rims	Syncros / 32H
