Photocells (option : Ref. AAM0036)
The photocells are safety devices for control automatic gates. Consist of one transmitter and one receiver
based in waterproof covers; it is triggered while breaking the path of the beams.
Once the photocells are connected, do not
forget to modify the H program and to set
H-1: Otherwise, the photocells will have no
effects on the opener (see page 16)
