Manual Version 19 / 01-2019 II Page 32 of 44
SF2 ECCR OPERATION MANUAL
NOTE
The quick coupling must NOT be used under water
To be taken apart. In particular in salt water it can
damage the contacts and cause costly repairs.
The controller of the SF2 has a waterproof plug connection which is secured as
shown in the second figure.
Finally, either the HUD or a Petrel Ext. Is connected to the Fischer socket. There
are separate operating instructions for both devices which must also be read
carefully. The SF2 ECCR is now ready to dive.
