1.3.11 Filling with fuel
The fuel is highly flammable and its vapours are combustible.
Filling should be carried out with the engine turned off. Smoking, using a naked flame or
producing sparks are forbidden while the fuel tank is being filled.
All traces of fuel should be wiped off with a clean cloth.
Danger
Storage and handling of petroleum products must be carried out in accordance with the law. Close the fuel tap (if fitted) each time the
tank has been filled. Never top up fuel when the generating set is in operation or hot.
Always place the generating set on a flat, level and horizontal surface to avoid fuel spilling onto the motor. Fill the tank with a funnel
taking care not to spill the fuel, then screw the plug back onto the fuel tank.
1.3.12 Safety guidelines for handling batteries
Never leave the battery close to a flame or fire.
Use only insulated tools.
Never use sulphuric acid or acid water to top up the electrolyte level.
Danger
2. Description
Figure A
1 Earth connection 7 Recoil-starter 13 Fuel filter
2 Oil level gauge 8 Circuit breakers 14 Air filter
3 Oil filler plug 9 Electrical sockets 15 Starter battery
4 Fuel tank plug 10 Stop lever 16 Exhaust silencer
5 Starting and shut-down key 11 Oil drain plug
6 Solenoid valve 12 Oil filter
Figure B
1 Oil gauge 3 Lower limit of gauge 5 Screw
2 Upper limit of gauge 4 Oil drain plug 6 Oil filter
Figure C
1 Fuel tank exit hose 2
Input & return hoses for the fuel
filter
3 Fuel filter screw
Figure D
1 Nut for the air filter cover 3 Wing nut 5 Paper element
2 Air filter cover 4 Foam element 6 Rubber gasket
3. Preparation before use
3.1. Positioning the generating set for operation
Choose a site that is clean, well ventilated and sheltered from bad weather.
Place the generating set on a flat, horizontal surface which is firm enough to prevent the set sinking down (under no circumstances
should the set tilt in any direction by more than 10°).
Store the additional supplies of oil and fuel within close proximity, whilst maintaining a certain distance for safety.
3.2. Earthing the generating set
The generating sets supply electrical current when in operation: risk of electrocution.
Connect the generating set to the ground at each use.
Dange
To connect the set to the ground: Attach a 10 mm
2
copper wire to the set’s earth connection and to a galvanised steel earthing rod
driven 1 meter into the ground.
