10. Specifications
Model HX 6000 C
Engine type Honda GX 390
Maximum output / Rated output 6000 W / 4800 W
Direct current X
Alternating current 230V - 20.9A
Socket type 1 x 2P+T 230V 10/16A 1 x 2P+T 230V 32A
Circuit breaker ●
Oil guard ●
Battery X
Acoustic pressure at 1 m 87 dBA
Weight in kg (without fuel) 75
Dimensions l x w x h in cm 71.5 x 57 x 59
Recommended oil SAE 10W30
Oil sump capacity in L 1.1
Recommended fuel Unleaded petrol
Fuel tank capacity in litres 6.1
Spark plug NGK BPR6ES / DENSO : W20 EPR-U
●: standard ○: optional X: impossible
11. Cable sizes
Rated current
(A)
Cable lengths
0 – 50 metres 51 – 100 metres 101 – 150 metres
6 1.5 mm
2
1.5 mm
2
2.5 mm
2
8 1.5 mm
2
2.5 mm
2
4.0 mm
2
10 2.5 mm
2
4.0 mm
2
6.0 mm
2
12 2.5 mm
2
6.0 mm
2
10.0 mm
2
16 2.5 mm
2
10.0 mm
2
10.0 mm
2
18 4.0 mm
2
10.0 mm
2
10.0 mm
2
24 4.0 mm
2
10.0 mm
2
16.0 mm
2
26 6.0 mm
2
16.0 mm
2
16.0 mm
2
28 6.0 mm
2
16.0 mm
2
16.0 mm
2
12. EC Declaration of conformity
Name and address of manufacturer: SDMO, 12 bis rue de la Villeneuve, CS 92848, 29228 BREST CEDEX 2, FRANCE
Description of the equipment Generating set
Make SDMO
Type HX 6000 C
Name and address of the person authorised to create and keep the technical file
G. Le Gall, SDMO, 12 bis rue de la Villeneuve, CS 92848, 29228 BREST CEDEX 2, FRANCE
G. Le Gall, the manufacturer's authorised representative, hereby declares that the equipment, if installed inside soundproofe
d
premises(*), complies with the following EU Directives:
2006/42/EC / Machinery Directive.
2006/95/EC / Low Voltage Directive.
2004/108/EC / Directive on Electromagnetic Compatibility.
01/2010 - G. Le Gall
(*) In this instance, Directive 2000/14/EC dated 08/05/2000 relating to noise
emission in the environment by equipment for use outdoors is not applicable. This
equipment must be installed in compliance with safety regulations by an approved
professional (consult us).
