HotFind-D Infrared Camera Operation Manual
9
3 SDS HotFind-D Interface Definition
2
1
3
4
1. Power supply interface
External 8V DC input interface
2. USB interface
Standard USB interface connect to PC
3. Video output interface
Standard RCA interface
4. RS232 interface
RS232 standard interface ( Only for firmware Upgrade)
