HotFind-D Infrared Camera Operation Manual
27
The psudocolor and color scale are displayed on the right. The color
bar in the middle represents psudocolors.
(2) Status bar
The status bar is displayed at the bottom of the screen，from left to
right：image condition(A), operation condition(B), the emissivity of the
target point (C), power status (D), alarm condition (E)and the current time
(F).
The definition of operation status as below :
“Null”: Idle;
“Menu”: Currently in Menu mode;
“SP1”: Currently in the analysis mode of “Spot 1”; press the key “C”
to clear the analysis of “Spot 1” and return to “Null” status; the spot 2,
spot 3 and highest/lowest spot are the same as spot 1;
“Iso”: Isotherm status.
Press the key “C” to clear the current analysis, and all the other
analyses status will not be influenced. Select and confirm the options
under the menu to enter the other analysis status.
Press the key “A” to save the analysis and return to “Null” status in
all the analysis status except “Null” and “Menu”. Select the options under
the menu again to enter the previous or other analysis status.
5.4 Adjustment of Infrared Camera
5.4.1 Adjustment of focusing
Point the camera to the target and focus the image manually.
5.4.2 Adjustment of Image (applicable to “Null” and “Menu” status)
In “Null” or “Menu” status, press the key “A”, and SDS HotFind-D will
automatically adjust the obtained image according to the setups under
the Setup-Image submenu to achieve the optimum effects.
