Seada SDCP6 - 5 Specification

Wallplate Control Panel-6 buttons
Website: www.seada.co.uk 22/23 E-mail: sales@seada.co.uk
5. Specification
Program Port
TCP/IP
Output Port
3 x RS232, 2 x IR
Output Connector
3 x 3-Pin Pluggable terminal blocks,
2 x 2-Pin Pluggable terminal blocks,
Baud Rate and Protocol
9600 baud, 8 data bits, 1 stop bit, no
parity
Software
SDCP6
Power Consumption
1W (Max)
Operation Temperature
0 ~ +40℃
Storage Temperature
-10 ~ +55℃
Relative Humidity
10% ~ 90%
Power Supply
Input: 100VAC~240VAC, 50/60 Hz;
Output: 12VDC 1A
Net Weight
About 200g
Dimension（W*H*D）
80mm x 151mm x 41mm (EU)
86mm x146mm x 36.8mm (UK)
