Ambient Cabinet Assembly
ITEM PART NO. DESCRIPTION
1 SAI88002A CABINET (5-WIDE AMBIENT)
1 SAI70006A CABINET (4-WIDE AMBIENT)
2 STI900 RAIL, TRAY, LEFT
3 STI901 RAIL, TRAY, RIGHT
4 STI573A LEGS
5 SAI778 SUPPORT, DOOR
6 HAI705 LEVELER, LEG
7 SAI88004 ASSEMBLY, ELECTRICAL BOX
8 STI70039 PANEL, WIRING DIAGRAM
9 STI70034 COVER, TRANSFORMER
10 HAC910 SPLIT NUT, T-HANDLE LOCK
11 STI87038 BRACKET, SPLIT NUT MOUNTING
12 ELI989 STABILIZER (OPTIONAL)
