DELIVERY SYSTEM
Your vendor consists of the Keypad, 2 Line VF Display, Driver Motors, Product Trays, Helix Coils and Delivery
Bin. The customer inserts money and enters their selecon on the Keypad. The selecon’s Driver Motor
turns the Helix Coil that vends the product into the Delivery Bin.
PRODUCT TRAYS
Your vendor features lock and release product trays. On the right side of each product tray you will nd a
Locking Lever (Fig. 14). To pull out the Product Tray, push down on the Locking Lever and roll toward you to
load posion.
PRICE SCROLLS AND SELECTION LABELS
Price scrolls are ed to each tray posion. To adjust the pricing display, use your thumb or nger to rotate
the scroll to show the desired price (Fig. 15). Note: this does not change the price of the item but only the
display. The actual price must be changed via the service mode menus detailed in this manual. Note that
there is a blank, white square at the end of the scroll case you need to write in a price not printed on the
scroll.
