70Revision 2.EL950 1.3.1074C 18.6
Vigilant Vend Sensor, Left Side Assembly
ITEM PART NO. DESCRIPTION
1 STI70086 SENSOR BRACKET
2 PLI609A SPACER
3 ELI2169 DETECTOR
4 FAI922 NUT
