Seagate BarraCuda Pro SATA Product Manual, Rev. D 28
67 Minimum PIO cycle time without IORDY flow control (240 ns) 0078
H
68 Minimum PIO cycle time with IORDY flow control (120 ns) 0078
H
69 Additional supported 0008
H
70–74 ATA-reserved 0000
H
75 Queue depth 001F
H
76 Serial ATA capabilities 8D0E
H
77 (Bit 6:1) Send/Receive FPDMA Queued Commands Supported xx4x
H
78 Serial ATA features supported xxxx
H
79 Serial ATA features enabled xxxx
H
80 Major version number 07F0
H
81 Minor version number 0060
H
82 Command sets supported 306B
H
83 Command sets supported 7561
H
84 Command sets support extension (see note following this table)
6173
H
85 Command sets enabled 3069
H
86 Command sets enabled B441
H
87 Command sets enable extension 6173
H
88 Ultra DMA support and current mode (see note following this table) xx7F
H
89 Security erase time xxxx
H
90 Enhanced security erase time xxxx
H
92 Master password revision code FFFE
H
93 Hardware reset value xxxx
H
95–99 ATA-reserved 0000
H
100–103
Total number of user-addressable LBA sectors available (see Section for related informa-
tion). These words are required for drives that support the 48-bit addressing feature. Maxi-
mum value: 0000FFFFFFFFFFFFh.
ST10000DM0004 = 19,532,873,728
ST8000DM0004 = 15,628,053,168
104–105 ATA-reserved 0000
H
106 Physical/Logical sector size 6003
H
107 ATA-reserved 0000
H
108–111 The mandatory value of the world wide name (WWN) for the drive.
NOTE: This field is valid if word 84, bit 8 is set to 1 indicating 64-bit WWN support.
Each drive will have a unique value.
112–118 ATA-reserved 0000
H
119 Commands and feature sets supported 41DE
H
120 Commands and feature sets supported or enabled 409C
H
121-127 ATA-reserved 0000
H
128 Security status 0021
H
129–159 Seagate-reserved xxxx
H
160–205 ATA-reserved 0000
H
206
SCT Command Transport command set.
If bit 0 is set to one, then the device supports SCT Command Transport.
Bits 7:2 indicate individual SCT feature support.
xxBD
H
207-254 ATA-reserved 0000
H
255 Integrity word xxA5
H
Note
See the bit descriptions below for words 63, 84, and 88 of the Identify Drive data.
Word Description Value
