Seagate BarraCuda Pro SATA Product Manual, Rev. D 6
2.0 Drive specifications
Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the
phrases the drive and this drive are used throughout this manual to indicate the following drive models
2.1 Specification summary tables
The specifications listed in the following tables are for quick reference. For details on specification measurement or definition, see the
appropriate section of this manual.
Table 1 Drive specifications summary
Standard 512E models
ST10000DM0004
ST8000DM0004
Drive specification* ST10000DM0004 ST8000DM0004
Formatted (512 bytes/sector)** 10TB 8TB
Guaranteed sectors (see Section 2.2)
Heads 14
Discs 7
Bytes per logical sector 512
Bytes per physical sector 4096
Recording density, KBPI (Kb/in max) 2230
Track density, KTPI (ktracks/in avg.) 386
Areal density, (Gb/in
2
avg) 867
Spindle speed (RPM) 7200
Internal data transfer rate (Mb/s max) 2695
Max sustained transfer rate, OD read (MB/s) 220
I/O data-transfer rate (MB/s max) 600
ATA data-transfer modes supported
PIO modes 0–4
Multiword DMA modes 0–2
Ultra DMA modes 0–6
Cache buffer 256MB
Weight: (maximum) 650g (1.43 lb)
Average latency 4.16ms
Power-on to ready (sec) (typ/max) 20/30
Standby to ready (sec) (typ/max) 20/30
Startup current (typical) 12V (peak) <=1.8A
Voltage tolerance (including noise)
5V ±5%
12V ±10%
Non-Operating (Ambient °C) –40° to 70°
Operating ambient temperature (min °C) 0°
Operating temperature (drive case max °C) 60°
†
Temperature gradient (°C per hour max)
20°C (operating)
30°C (non-operating)
Relative humidity
5% to 95% (operating)
5% to 95% (non-operating)
Relative humidity gradient 30% per hour max
Altitude, operating
–304.8 m to 3,048 m
(–1000 ft to 10,000+ ft)
Altitude, non-operating
(below mean sea level, max)
–304.8 m to 12,192 m
(–1000 ft to 40,000+ ft)
Operational Shock (max at 2 ms) Read 70 Gs / Write 40 Gs
Non-Operational Shock (max at 2 ms) 250 Gs
