SV35 Series SATA Product Manual, Rev. B
2.8.1.1 Typical current profiles
Figure 1 Typical 5V startup and operation current profile
Figure 2 Typical 12V startup and operation current profile
Table 4: DC power requirements
Power dissipation (typical)
Example: ST3500641SV Average (watts, 25° C) 5V typ amps 12V typ amps
Spinup — — 2.0 (peak)
Idle 6.9 0.353 0.519
Operating (DVR Storage Profile) 8.44 0.478 0.50
Seeking 12.60 0.613 0.795
Standby 0.80 0.106 0.023
Sleep 0.80 0.106 0.023
