SV35 Series SATA Product Manual, Rev. B
53 Words 54–58, 64–70 and 88 are valid 0007
H
54 Number of current logical cylinders xxxx
H
55 Number of current logical heads xxxx
H
56 Number of current logical sectors per logical track xxxx
H
57–58 Current capacity in sectors xxxx
H
59 Number of sectors transferred during a Read Multiple or Write Multiple
command
xxxx
H
60–61 Total number of user-addressable LBA sectors available
(see Section 2.2 for related information)
*Note: The maximum value allowed in this field is: 0FFFFFFFh
(268,435,455 sectors, 137 Gbytes). Drives with capacities over 137
Gbytes will have 0FFFFFFFh in this field and the actual number of
user-addressable LBAs specified in words 100-103. This is required for
drives that support the 48-bit addressing feature.
0FFFFFFFh*
62 Retired 0000
H
63 Multiword DMA active and modes supported (see note following this
table)
xx07
H
64 Advanced PIO modes supported (modes 3 and 4 supported) 0003
H
65 Minimum multiword DMA transfer cycle time per word (120 nsec) 0078
H
66 Recommended multiword DMA transfer cycle time per word (120 nsec) 0078
H
67 Minimum PIO cycle time without IORDY flow control (240 nsec) 00F0
H
68 Minimum PIO cycle time with IORDY flow control (120 nsec)
0078
H
69–74 ATA-reserved 0000
H
75 Queue depth 0000
H
76 Serial ATA capabilities xxxx
H
77 Reserved for future Serial ATA definition xxxx
H
78 Serial ATA features supported xxxx
H
79 Serial ATA features enabled xxxx
H
80 Major version number 003E
H
81 Minor version number 0000
H
82 Command sets supported 364B
H
Word Description Value
