Seagate ST318436LW - Figure 3 B. Typical Barracuda 18 XL Family Drive +5 V Current Profile

24 Barracuda 18XL Product Manual, Rev. A
s
Figure 3b. Typical Barracuda 18XL family drive +5 V current profile
0.0 2 4 6 8 10 12 14 16 18 20
0.0
0.2
0.4
0.8
1.0
1.2
0.6
A
Seconds
+5 Volt Current, SCSI SE, during spindle start – Typical Amperes
T1 T3
T2
T
T4
T5
