Seagate ST318436LW - Figure 11 B. Nonshielded 80 Pin SCSI SCA-2 Connector, Used on LC Models

70 Barracuda 18XL Product Manual, Rev. A
Figure 11b. Nonshielded 80 pin SCSI “SCA-2” connector, used on “LC” models
7.00
(.276)
12.70
(.500)
2.15±0.10
2 places
57.87
(2.278)
–Y–
0.15
MYM
0.15
MYM
0
–0.15
+ .000
– .006
[
[
62.15
(2.447)
± 0.15
(± .005)
Housing
X
X
Contact
0.3
(.012)
MYM
1.27
(.05)
Typ
C
L
of Datum Y
C
L
of Datum Y
0.50
(.020)
Pin 1 Pin 40
Pin 41 Pin 80
Pin 1
Front View
End View
Top View
Back View
Insert mating
I/O connector
Grounding
Pins
Grounding
Pins
