52 Barracuda 18XL Product Manual, Rev. A
The following tables list the values of the data bytes returned by the drive in response to the Mode Sense com-
mand pages (see the SCSI Interface Product Manual, P/N 75789509).
Definitions:
SAV = Saved value
DEF = Default value. Standard drives are shipped configured this way.
CHG = Changeable bits; indicates if current and saved values are changeable.
Notes [ ].
See Section 9.3.2.1.
Table 9a: Mode sense data, ST318436 values
Bytes 00010203040506070809101112 1314151617181920212223
Mode
Sense
Data
9F 00 10 08 02 23 90 70 00 00 02 00
Mode
Page
<------------------------------Mode Page Headers and Parameter Data Bytes---------------------------->
01 SAV
81 0A C0 0B F0 00 00 00 0F 00 FF FF
01 DEF 81 0A C0 0B F0 00 00 00 0F 00 FF FF
01 CHG 81 0A FF FF 00 00 00 00 FF 00 FF FF
02 SAV 82 0E 80 80 00 0A 00 00 00 00 00 00 00 00 00 00
02 DEF 82 0E 80 80 00 0A 00 00 00 00 00 00 00 00 00 00
02 CHG 82 0E FF FF 00 00 00 00 00 00 00 00 87 00 00 00
03 SAV 83 16 01 68 00 00 00 02 00 00 01 A1 02 00 00 01 00 36 00 36 40 00 00 00
03 DEF
83 16 01 68 00 00 00 02 00 00 01 A1 02 00 00 01 00 36 00 36 40 00 00 00
03 CHG
83 16 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
04 SAV 84 16 00 38 30 06 00 00 00 00 00 00 00 00 00 00 00 00 00 00 1C 05 00 00
04 DEF
84 16 00 38 30 06 00 00 00 00 00 00 00 00 00 00 00 00 00 00 1C 05 00 00
04 CHG
84 16 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
07 SAV 87 0A 00 0B F0 00 00 00 00 00 FF FF
07 DEF 87 0A 00 0B F0 00 00 00 00 00 FF FF
07 CHG 87 0A 0F FF 00 00 00 00 00 00 FF FF
08 SAV 88 12 14 00 FF FF 00 00 FF FF FF FF 80 [3] 00 00 00 00 00 00
08 DEF 88 12 14 00 FF FF 00 00 FF FF FF FF 80 10 00 00 00 00 00 00
08 CHG 88 12 B5 00 00 00 FF FF FF FF 00 00 A0[1] FF 00 00 00 00 00 00
0A SAV 8A 0A 02 00 00 00 00 00 00 00 04 E7
0A DEF 8A 0A 02 00 00 00 00 00 00 00 04 E7
0A CHG 8A 0A 03 F1 00 00 00 00 00 00 00 00
1A SAV 9A 0A 00 03 00 00 00 01 00 00 00 04
1A DEF 9A 0A 00 03 00 00 00 01 00 00 00 04
1A CHG 9A 0A 00 03 00 00 00 00 00 00 00 00
1C SAV 9C 0A 00 00 00 00 00 00 00 00 00 01
1C DEF 9C 0A 00 00 00 00 00 00 00 00 00 01
1C CHG 9C 0A 8D 0F FF FF FF FF FF FF FF FF
00 SAV 80 02 [2] 00
00 DEF 80 02 80 00
00 CHG 80 02 F7 40
