Seagull Models SPACE WALKER II - Installation Pilot; Attachment Wing-Fuselage

SPACE WALKER II Instruction Manual
18
 1) Plug the six servo leads and the switch
lead into the receiver. Plug the battery pack
lead into the switch also.
 2) Wrap the receiver and battery pack in
the protective foam rubber to protect them
from vibration.
 3) Route the antenna in the antenna tube
inside the fuselage and secure it to the bot-
tom of fuselage using a plastic tape.
INSTALLING THE BATTERY-RECEIVER.
ATTACHMENT WING-FUSELAGE.
Attach the aluminium tube into fuselage.
Insert two wing panels as pictures below.
Machine Screw 2 x 8mm.
Silicon glue.
Silicon glue.
60mm.
60mm.
2x8mm.
Antenna.
wing tube.
15mm.
15mm.
Silicon glue pilot.
Battery.
Receiver.
INSTALLATION PILOT.
