Seagull Models SPACE WALKER II - Landing Gear and Wheel Assembly; Wheel and Wheel Pants Installation

SPACE WALKER II Instruction Manual
6
 1) Assemble and mounting the wheel pants
as shown in the following pictures.
 2) Follow diagram below for wheel pant
installation:
Blow through one of the lines to ensure
the fuel lines have not become kinked in-
side the fuel tank compartment. Air should
flow through easily.
WHEEL AND WHEEL PANTS INSTALLA-
TION.
Fuel pick-up tube.
Fuel fill tube.
Vent tube.
(2) Wheel Collar.
Axle.
Wheel.
Nut.
Nut.
(2) Washer.
Rubber band.
Fuel tank.
Wheel Collar.
Axle.
Wheel.
Nut.
Wheel Pant.
Landing Gear.
Nut.
(2) Washer.
7mm
14mm
Lite -Plywood
block.
