Sealey G3500I - INTRODUCTION; Generator Technology Overview; SPECIFICATION; Generator Technical Details

8 DO NOT store generator with fuel in tank where petrol vapours might reach an open flame or spark.
9 The generator must be grounded with a good quality insulated conductor.
9 Keep vents free from dirt etc.
9  Ifsupplyingelectronicequipment,orinanareawhereelectronicequipmentisbeingused,keepthegeneratorasufcientdistance
away to prevent electrical noise from the engine.
9 Before use, the generating set and its electrical equipment (including lines and plug connections) should be checked to ensure that
they are not defective.
9 Generator must be earthed with a good quality insulated conductor.
2. INTRODUCTION
Digital inverter technology provides pure sine wave electric power suitable for use with sensitive electrical equipment. Easily moveable with
folded handle and sturdy wheels making it portable once on site. Eco mode set-up allowing the generator to run quieter (73dB LPA), increase
fuelefciency(8Lfueltank)andreduceemissions.Featuresbothpullcordandswitchstart,autovoltageadjustor,fuelgaugesensor,electric
circuitprotectorandESCsmartcontrolallowingthespeedoftheengine.Fittedwithtwo13Asockets,12VDC8.3Aportand2USBcharging
ports. Supplied with tool kit to access battery, funnel, connector and clips which can charge a 12V car battery.
3. SPECIFICATION
Model No .................................................................... G3500I
Continuous Power Rating:...........................................3200W
Current Rating: ..............................................................13.9A
Dimensions (W x D x H): ......................... 590 x 456 x 511mm
Fuel Tank: ....................................................................... 8.3L
Fuel: ..............................................................Unleaded Petrol
Maximum Power Rating: ..............................................3.5kW
Maximum Running Time:
.........................RatedLoad-5±0.5hrs50%load-8.5±0.5hrs
Motor Power: ................................................ 4.1KW/3600rpm
Motor Type: .................................................... 4-Stroke Petrol
Noise Rating: ........................................................73dB(LPA)
Output: ................................. 230V ~ 50Hz/ 12V DC/ 5V USB
4. FEATURES
See above right
5. CONTROLS
5.1. SWITCH KNOB POSITIONS
5.1.1. OFF: Engine switch\fuel valve “OFF”; Ignition circuit is switched off.
Fuel is switched off. The engine will not run.
5.1.2. CHOKE/START: Engine switch \fuel valve \ choke “ON” ;
Ignition circuit is switched on. Fuel is switched on.
Choke is switched on. The engine will run.
5.1.3. RUN: Ignition circuit is switched on. Fuel is switched on. Choke is switched off.
Note: The choke is not required to start a warm engine.
5.2. OIL WARNING LIGHT 13
When the oil level falls below the lower level, the oil warning light 13 comes on and then the engine stops automatically. Unless the
engine is topped up with oil, the engine will not start again.
Note: If the engine stalls or does not start, turn the engine switch to RUN and then pull the recoil starter.
1. AC reset
2. ESC
(Engine Smart Control)
3. AC sockets
4. Parallel outlets
5. Ground (earth) terminal
6. USB
7. DC socket
8.DCbreaker
9. Electric start switch
10. Switch
11. AC pilot light
12. Overload indicator
13. Oil warning light
Original Language Version
© Jack Sealey Limited
g.1
G3500I Issue 1 10/02/23
