Sealey G3500I - Air Filter Cleaning; Muffler Screen and Spark Arrester; Fuel Tank Filter Cleaning; STORAGE

8.10. AIR FILTER FIG.7
8.10.1. Removethescrewsg.7.1,andthenremovethecoverg.7.2.
8.10.2. Removetheairltercasecoverg.7.3.
8.10.3. Remove the foam element.
8.10.4. Wash the foam element in detergent and dry it.
8.10.5. Oil the foam element and squeeze out excess oil. The foam element should be wet but not dripping.
8 DO NOT wring out the foam element when squeezing it. This could cause it to tear.
8.10.6. Insertthefoamelementintotheairltercase.NOTE:Besurethefoamelementsealingsurfacematchertheairltersothere 
are no air leaks.
8.10.7. The engine should never run without the foam element; excessive piston and cylinder wear may result.
8.10.8. Installtheairltercasecoverinitsoriginalposition.
8.10.9. Install the cover and lock it.
8.11. MUFFLER SCREEN AND SPARK ARRESTER FIG.8
 WARNING!Theengineandmuferwillbeveryhotaftertheenginehasbeenrun.Avoidtouchingtheengineandmuferwhilethey
are still hot with any part of your body or clothing during inspection or repair.
8.11.1. Removethescrewsg.8.1.
8.11.2. Removethemufercapg.8.2,themuferscreeng.8.3andsparkarresterg.8.4.
8.11.3. Cleanthecarbondepositsonthemuferscreenandsparkarresterusingawirebrush.
8.11.4. Whencleaning,usethewirebrushlightlytoavoiddamagingorscratchingofmuferscreenandsparkarrester.
8.11.5. Checkthemuferscreenandsparkarrester.Replacethemifdamaged.
8.11.6. Install the spark arrester. NOTE: Alignthesparkarresterprojectionwiththeholeinthemuferpipe.
8.11.7. Installthemuferscreenandthemufercap.
8.11.8. Install the cover and tighten the screws.
8.12. FUEL TANK FILTER
 WARNING! Neverusepetrolwhilstinthevicinityofanopenameorwhilstsmoking.
8.12.1. Removethefueltankcapandlter.
8.12.2. Cleanthelterwithpetrol.Wipethelterandinstallit.
8.12.3. Install the fuel tank cap. Be sure the fuel tank cap is tightened securely.
9. STORAGE
9.1. Long term storage of your machine will require some preventive procedures to guard against deterioration.
9.1.1.  Drainthefuel.Turntheswitchknobto“OFF”.Removethefueltankcap,removethelter.Extractthefuelfromthefueltankintoan
approved petrol container.
9.1.2. Replace the fuel tank cap.
9.1.3.  Fuelishighlyammableandpoisonous.Check“SAFETYINFORMATION”carefully.
9.1.4. Immediately wipe off spilled fuel with a clean, dry, soft cloth, since fuel may deteriorate painted surfaces or plastic parts.
9.1.5. Start the engine and leave it run until it stops by running out of fuel.
8 DO NOT connect with any electrical devices. (unloaded operation)
9.1.6. Duration of the running engine depends on the amount of the fuel left in the tank (approx. 20 mins).
9.1.7. Turn the switch 10 to “OFF”.
