23
SQUEEGEE SP300
WIRING CHART SP300
WIRING FOR RECTIFIER-ENGINE-IGNITION-HYD. COOLER-FAN RELAY
White/Blue on Rectifier N/A Grey/Grey on Rectifier to Grey/Grey on Engine
IGNITION
BLUE
GREEN
RED
YELLOW
BROWN
BLACK
BROWN-AUXILIARY, BLUE TO
FAN RELAY
RED FROM HOUR METER &
WATER PUMP OPTION
BLACK-STOP
RED-MAIN POWER
& 30 AMP FUSE
YELLOW-IGNITION
GREEN-GROUND &
BLACK FROM HOUR
METER
Blue to fan Relay
Black on Rectifier to Black Ground
White on Starter / to power Bolt
Starter Solenoid to male Plug
Yellow stripe/black stripe on Rectifier -
butt connect to: Yellow stripe/black
stripe- on Engine
Black from Engine-butt connect
HYDRAULIC OIL COOLER FAN MOTOR
Red to relay red
Black-butt connect then to black on
relay-then to ground
FAN RELAY SWITCH
Red from 20 amp fuse at battery-87
Red to red on fan motor-86
Black to black on fan motor-85
Blue -30
