29
SQUEEGEE SP300 DUAL/SPRAY
FILLING MATERIAL TANK:
23. When cutting material in the machine, always place sealer in
the tank before adding water.
24. Start the agitator by moving the agitator control valve #7 to
the forward position. Agitate speed with control speed knob on
agitator motor #21. Set agitator to a proper consistent speed.
25. To avoid a buildup of sand on the sides of the machine,
always pour sand into the center of the tank. The usual amount
of sand used to provide an anti-skid surface or to fill porous
pavement is three pounds per gallon of sealer. This will vary
according to the porosity of the surface you are sealing.
9 REAR ASSEMBLY UP
AND DOWN
8 REAR ASSEMBLY
LEFT AND RIGHT
74 CONTROL PANEL
ENGINE DISPLAY
72 PANEL FUSE HOLDER
& 73 FUSE 25 AMP
